GPHT1211 4.08 mm Grade CM1 Carbide Uncoated Neutral Hand Turning Insert
- Item Code: GPHT1211 CM1
- Brand: WIDIA
- Unit Size: 1
Description
Application Material: Most Steels, Stainless Steels, High-Temperature Alloys, Titanium, Irons, Non-Ferrous Materials
Uncoated carbide
A very tough, ultra-fine grain unalloyed substrate
For general-purpose machining of most steels, stainless steels, high-temperature alloys, titanium, irons, and non-ferrous materials
Performs best at low speeds and will handle interruptions and high feed rates
Use when C2, C3, or C25 fail due to chipping or breaking
Features
Back To Top- Small Hole Boring, Suitable for interrupted cuts.
Tech Specs
Back To Top| Cutting Edge Length | 0.2270 Inch |
|---|---|
| Inscribed Circle | 0.1605 Inch |
| Thickness | 0.0620 Inch |
| Included Angle | 45 |
| Corner Radius | 0.0150 Inch |
| Grade | CM1 |
| Insert Hole Size | 0.0840 Inch |
| Coating/Finish | None |
| Clearance Angle | 11 Degree |
| Product Type | Turning |
| Brand | WIDIA |
| Hand of Tool | Neutral |
| Shape | Diamond |
| Type | Screw-On |
| Insert Style | GPHT |
| Material | Solid Carbide |
| Number of Cutting Edges | 2 |
