GPHW1211 3.97 mm Grade CG5 Carbide TiN Coated Neutral Hand Turning Insert
- Item Code: GPHW1211-CG5
- Brand: WIDIA
- Unit Size: 1
Description
Application Material: Most Steels, Stainless Steels, High-Temperature Alloys, Titanium, Irons, Non-Ferrous Materials
PVD-TiN-coated carbide grade
Straight 9.5% Co substrate
Submicron grain
For general-purpose machining of most steels, stainless steels, high-temperature alloys, titanium, irons, and non-ferrous materials
Performs best at low speeds and will handle interruptions and high feed rates
Features
Back To Top- Small Hole Boring, Suitable for interrupted cuts.
Tech Specs
Back To Top| Clearance Angle | 11 Degree |
|---|---|
| Product Type | Turning |
| Included Angle | 45 |
| Grade | CG5 |
| Insert Hole Size | 0.0840 Inch |
| Number of Cutting Edges | 2 |
| Hand of Tool | Neutral |
| Thickness | 0.0620 Inch |
| Brand | WIDIA |
| Cutting Edge Length | 0.2210 Inch |
| Type | Screw-On |
| Corner Radius | 0.0150 Inch |
| Insert Style | GPHW |
| Material | Solid Carbide |
| Coating/Finish | TiN |
| Inscribed Circle | 5/32 Inch |
| Shape | Diamond |
