3/4 Inch Drive Deep Impact Socket 36 mm - 6 Point - Proto®

  • Item Code: J07536ML
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 6 Point Impact Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.
    • Stamped size for easy reference.
    • Side locking hole.

Tech Specs

Back To Top
Box Weight [lbs] 11.600
UPC Code 662679361099
Brand Proto
Item Length [in] 3.100
Item Width [in] 2.000
Crush Retaining Ring JRR07526
Size [mm] 36
Country of Origin United States
Point Size 6
Box Length [in] 13.370
Box Quantity 6
Box Height [in] 2.600
Item Height [in] 2.000
Nut Depth [in] 1
Nut End Outside Diameter [in] 2-1/4
Bolt Clearance Depth [in] 2-9/32
Item Weight [lbs] 1.910
Length [in] 3-1/4
Specification_ASME ASME B107.110-2012
Box Width [in] 3.250
Drive End Outside Diameter [in] 1-3/4
Drive Size [in] 3/4
Harmonization Code 8204200000
Item Quantity 1
Length Type Deep
Overall Length [in] 3-1/4
Finish Black Oxide
O-Ring J07500R
