#5 Spline Drive Impact Socket 2-3/16 Inch - 6 Point - Proto®

  • Item Code: J09935
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 6 Point Impact Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
Box Weight [lbs] 4.220
Item Weight [lbs] 4.280
UPC Code 662679400279
Item Length [in] 4.200
Item Width [in] 3.600
Point Size 6
Finish Black Oxide
Length [in] 3-3/4
Nut End Outside Diameter [in] 3-1/2
Bolt Clearance Depth [in] 1-39/64
Nut Depth [in] 1-3/8
Drive Size [in] #5 Spline
Harmonization Code 8204200000
Item Height [in] 3.600
Length Type Standard
Box Length [in] 3.900
Box Quantity 1
Box Width [in] 3.400
Country of Origin United States
Item Quantity 1
Box Height [in] 3.400
Brand Proto
Drive End Outside Diameter [in] 2-3/8
Overall Length [in] 3-3/4
Size [in] 2-3/16
