#5 Spline Drive Impact Socket 2-3/4 Inch - 6 Point - Proto®

  • Item Code: J09944
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 6 Point Impact Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
Carton Weight [lbs] 40.980
Item Length [in] 4.100
Nut Depth [in] 1-3/4
Nut End Outside Diameter [in] 4-1/4
UPC Code 662679400354
Drive End Outside Diameter [in] 2-3/8
Box Quantity 1
Brand Proto
Drive Size [in] #5 Spline
Item Height [in] 4.000
Box Height [in] 4.200
Carton Height [in] 8.500
Country of Origin United States
Harmonization Code 8204200000
Item Quantity 1
Bolt Clearance Depth [in] 1-59/64
Carton Length [in] 13.000
Carton Quantity 7
Carton Width [in] 9.100
Finish Black Oxide
Item Weight [lbs] 5.640
Overall Length [in] 4-1/4
Box Width [in] 4.200
Item Width [in] 4.000
Length [in] 4-1/4
Point Size 6
Box Length [in] 4.600
Box Weight [lbs] 6.940
Length Type Standard
Size [in] 2-3/4
