1 Inch Drive Impact Socket 15/16 Inch - 4 Point - Proto®

Price Break Details

Features Tech Specs

Drive end chamfer and four detents help provide quick positive engagement with drive tool on any of the socket drive walls.
Tight tolerances for snug fit on fastener.
Large clearance holes, concentric opening and nut end chamfer make it easy to position socket on fasteners.
Made from high-strength steel to help minimize wall thickness and provide access to fasteners in recesses and where nuts and bolts protrude.
Impact sockets are used wherever powered drive tools are used to install or remove fasteners.
Impact sockets are designed to withstand the high torque and force associated with impact tools in repetitive application.
Features two through holes and a groove to accept a Proto® Retaining Ring or pin and O-ring to help secure the socket to the drive tool anvil.

UPC Code	662679370206
Bolt Clearance Depth [in]	1-3/8
Country of Origin	United States
Crush Retaining Ring	JRR10028
Drive End Outside Diameter [in]	2-1/8
Item Weight [lbs]	1.800
Box Length [in]	13.370
Harmonization Code	8204200000
Item Quantity	1
Length Type	Standard
Nut Depth [in]	19/32
Overall Length [in]	2-1/2
Item Height [in]	2.000
Item Length [in]	2.500
Box Quantity	6
Finish	Black Oxide
Point Size	4
Size [in]	15/16
Box Width [in]	3.250
Drive Size [in]	1
Item Width [in]	2.000
Box Height [in]	2.600
Box Weight [lbs]	10.620
Length [in]	2-1/2
Nut End Outside Diameter [in]	2-1/16
O-Ring	J10000R1
Brand	Proto
