1 Inch Drive Impact Socket 1-1/8 Inch - 4 Point - Proto®

Price Break Details

Features Tech Specs

Drive end chamfer and four detents help provide quick positive engagement with drive tool on any of the socket drive walls.
Tight tolerances for snug fit on fastener.
Large clearance holes, concentric opening and nut end chamfer make it easy to position socket on fasteners.
Made from high-strength steel to help minimize wall thickness and provide access to fasteners in recesses and where nuts and bolts protrude.
Impact sockets are used wherever powered drive tools are used to install or remove fasteners.
Impact sockets are designed to withstand the high torque and force associated with impact tools in repetitive application.
Features two through holes and a groove to accept a Proto® Retaining Ring or pin and O-ring to help secure the socket to the drive tool anvil.

Box Weight [lbs]	11.660
Item Height [in]	2.250
Item Length [in]	2.690
UPC Code	662679977597
Drive End Outside Diameter [in]	2-3/8
Length [in]	2-1/2
Brand	Proto
Drive Size [in]	1
Finish	Black Oxide
Point Size	4
Box Quantity	6
Crush Retaining Ring	JRR10028
Item Width [in]	2.250
Nut End Outside Diameter [in]	2-1/4
O-Ring	J10000R1
Box Height [in]	2.500
Country of Origin	United States
Item Quantity	1
Nut Depth [in]	23/32
Size [in]	1-1/8
Bolt Clearance Depth [in]	1-3/8
Box Length [in]	15.700
Box Width [in]	3.300
Harmonization Code	8204200000
Item Weight [lbs]	1.800
Overall Length [in]	2-1/2
Length Type	Standard
