1 Inch Drive Impact Socket 1-3/16 Inch - 6 Point - Proto®

  • Item Code: J10019
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 6 Point Impact Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
Box Weight [lbs] 9.190
Item Length [in] 2.650
UPC Code 662679370312
Length [in] 2-5/8
Nut End Outside Diameter [in] 1-7/8
Bolt Clearance Depth [in] 1-1/2
Item Weight [lbs] 1.500
Box Height [in] 2.500
Box Quantity 6
Country of Origin United States
Nut Depth [in] 7/8
Brand Proto
Drive Size [in] 1
Overall Length [in] 2-5/8
Point Size 6
Size [in] 1-3/16
Specification_ASME ASME B107.110-2012
Crush Retaining Ring JRR10028
Item Width [in] 2.000
O-Ring J10000R1
Box Width [in] 3.300
Drive End Outside Diameter [in] 2-1/8
Finish Black Oxide
Box Length [in] 15.700
Harmonization Code 8204200000
Item Height [in] 2.000
Item Quantity 1
Length Type Standard
