1 Inch Drive Impact Socket 3-3/8 Inch - 6 Point - Proto®

  • Item Code: J10054
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 6 Point Impact Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
Bolt Clearance Depth [in] 2-15/32
Item Weight [lbs] 7.800
Nut End Outside Diameter [in] 4-9/16
UPC Code 662679370954
Specification_ASME ASME B107.110-2012
Box Weight [lbs] 7.400
Length Type Standard
Point Size 6
Box Quantity 1
Crush Retaining Ring JRR10040
Drive Size [in] 1
Item Quantity 1
Nut Depth [in] 2-1/4
Drive End Outside Diameter [in] 2-3/8
Item Height [in] 4.800
O-Ring N/A
Country of Origin United States
Length [in] 4-7/16
Size [in] 3-3/8
Box Length [in] 4.500
Brand Proto
Finish Black Oxide
Harmonization Code 8204200000
Item Length [in] 5.200
Overall Length [in] 4-7/16
Box Height [in] 4.500
Item Width [in] 4.800
Box Width [in] 4.500
