Satin Combination Wrench 1-3/16 Inch - 6 Point - Proto®
- Item Code: J1238HASD
- Brand: Proto
- Unit Size: 1
Description
Satin finish provides corrosion resistance and a slip resistant grip.
6 point box end allows for large wrench to fastener contact area which helps prevent rounding of the fastener.
Fractional sizes 11/32" and smaller and sizes 1-5/16" and larger do not have the ASD feature.
Box ends incorporate the TorquePlus™ system.
Features
Back To Top- Satin finish provides corrosion resistance and a slip resistant grip.
- 6 point box end allows for large wrench to fastener contact area which helps prevent rounding of the fastener.
- Fractional sizes 11/32" and smaller and sizes 1-5/16" and larger do not have the ASD feature.
- Box ends incorporate the TorquePlus„¢ system.
Tech Specs
Back To Top| Box Weight [lbs] | 9.770 |
|---|---|
| Carton Weight [lbs] | 48.600 |
| Item Length [in] | 15.700 |
| Opening Size [in] | 2-25/64 |
| UPC Code | 662679087456 |
| Box Height [in] | 3.600 |
| Box Quantity | 6 |
| Country of Origin | United States |
| Head Thickness 1 [in] | 3/4 |
| Carton Height [in] | 6.800 |
| Brand | Proto |
| Outside Head Width 2 [in] | 1-21/32 |
| Point Size | 6 |
| Outside Head Width 1 [in] | 2-25/64 |
| Throat Depth 1 [in] | 1-23/64 |
| Box Width [in] | 4.600 |
| Head Thickness 2 [in] | 21/32 |
| Item Width [in] | 2.400 |
| Size [in] | 1-3/16 |
| Thread Size [in] | 1-23/64 |
| Box Length [in] | 18.800 |
| Carton Width [in] | 10.100 |
| Finish | Satin |
| Offset Angle | 15° |
| Overall Length [in] | 15-7/8 |
| Specification_ASME | ASME B107.100 |
| Bend Angle | 15° |
| Carton Length [in] | 20.800 |
| Harmonization Code | 8204110030 |
| Item Quantity | 1 |
| Item Weight [lbs] | 1.630 |
| Carton Quantity | 30 |
| Item Height [in] | 0.900 |
