1-1/2 Inch Drive Deep Impact Socket 3-9/16 Inch - 6 Point - Proto®

  • Item Code: J15057L
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 6 Point Impact Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.
    • Stamped size for easy reference.
    • Side locking hole.

Tech Specs

Back To Top
Bolt Clearance Depth [in] 4-5/16
Box Weight [lbs] 17.240
Item Height [in] 5.500
Item Weight [lbs] 22.110
Nut Depth [in] 2-15/16
Size [in] 3-9/16
UPC Code 662679380779
Harmonization Code 8204200000
Item Quantity 1
Overall Length [in] 6-3/4
Box Quantity 1
Country of Origin United States
Item Length [in] 6.700
Nut End Outside Diameter [in] 5-1/8
Point Size 6
Box Height [in] 5.300
Drive End Outside Diameter [in] 3-1/4
Finish Black Oxide
Brand Proto
Length Type Deep
Box Length [in] 6.700
Box Width [in] 5.300
Drive Size [in] 1-1/2
Item Width [in] 5.500
Length [in] 6-3/4
Specification_ASME ASME B107.110-2012
