1/4 Inch Drive Socket 1/4 Inch - 8 Point - Proto®

  • Item Code: J4708S
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 8 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded or rusted fasteners.

Tech Specs

Back To Top
UPC Code 662679140267
Country of Origin United States
Nose Width [in] 31/64
Box Quantity 6
Box Weight [lbs] 0.190
Brand Proto
Drive Size [in] 1/4
Item Weight [lbs] 0.030
Nut Depth [in] 1/4
Size [in] 1/4
Box Length [in] 4.500
Harmonization Code 8204200000
Item Quantity 1
Nut End Outside Diameter [in] 31/64
Drive End Outside Diameter [in] 31/64
Bolt Clearance Depth [in] 17/32
Box Height [in] 1.250
Item Length [in] 0.900
Length [in] 7/8
Item Height [in] 0.400
Length Type Standard
Box Width [in] 2.250
Item Width [in] 0.400
Finish Full Polish
Overall Length [in] 7/8
Point Size 8
Specification_ASME ASME B107.110-2012
