1/4 Inch Drive Socket 5/16 Inch - 8 Point - Proto®

  • Item Code: J4710S
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 8 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded or rusted fasteners.

Tech Specs

Back To Top
UPC Code 662679140397
Box Weight [lbs] 0.240
Box Width [in] 2.250
Size [in] 5/16
Drive End Outside Diameter [in] 9/16
Finish Full Polish
Overall Length [in] 7/8
Specification_ASME ASME B107.110-2012
Bolt Clearance Depth [in] 17/32
Box Height [in] 1.250
Country of Origin United States
Item Length [in] 0.900
Nut End Outside Diameter [in] 9/16
Point Size 8
Item Width [in] 0.500
Box Quantity 6
Drive Size [in] 1/4
Item Height [in] 0.500
Nut Depth [in] 1/4
Box Length [in] 4.500
Brand Proto
Harmonization Code 8204200000
Item Quantity 1
Item Weight [lbs] 0.050
Length [in] 7/8
Length Type Standard
