3/8 Inch Drive Deep Socket 7/16 Inch - 12 Point - Proto®

  • Item Code: J5014
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 12 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded or rusted fasteners.

Tech Specs

Back To Top
Nut End Outside Diameter [in] 21/32
Specification_ANSI B209.2
Specification_USGovernment GGG-P-831e
UPC Code 662679160791
Bolt Clearance Depth [in] 1-11/16
Brand Proto
Carton Quantity 260
Carton Width [in] 5.400
Carton Height [in] 6.000
Finish Full Polish
Item Height [in] 0.600
Item Width [in] 0.600
Length Type Deep
Point Size 12
Size [in] 7/16
Specification_ASME ASME B107.110-2012
Carton Length [in] 15.300
Drive Size [in] 3/8
Specification_AS AS954E S3.8.1
Box Height [in] 1.250
Drive End Outside Diameter [in] 21/32
Box Length [in] 4.500
Box Weight [lbs] 0.720
Box Width [in] 2.250
Item Weight [lbs] 0.120
Box Quantity 6
Country of Origin United States
Nut Depth [in] 7/16
Carton Weight [lbs] 31.770
Harmonization Code 8204200000
Item Length [in] 2.200
Item Quantity 1
Overall Length [in] 2-1/8
