3/8 Inch Drive Deep Socket 7/16 Inch - 6 Point - Proto®

  • Item Code: J5014H
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 6 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded or rusted fasteners.

Tech Specs

Back To Top
Carton Weight [lbs] 31.770
Nut End Outside Diameter [in] 41/64
UPC Code 662679160807
Box Quantity 6
Nose Width [in] 41/64
Box Length [in] 4.800
Box Weight [lbs] 0.720
Item Weight [lbs] 0.120
Carton Width [in] 5.400
Length [in] 2-1/8
Box Height [in] 1.350
Carton Length [in] 15.300
Item Quantity 1
Overall Length [in] 2-1/8
Box Width [in] 2.350
Brand Proto
Carton Height [in] 6.000
Item Height [in] 0.600
Item Width [in] 0.600
Length Type Deep
Size [in] 7/16
Bolt Clearance Depth [in] 1-11/16
Carton Quantity 260
Harmonization Code 8204200000
Point Size 6
Drive End Outside Diameter [in] 41/64
Item Length [in] 2.100
Country of Origin United States
Drive Size [in] 3/8
Finish Full Polish
Nut Depth [in] 7/16
Specification_ASME ASME B107.110-2012
