3/8 Inch Drive Deep Socket 5/8 Inch - 12 Point - Proto®

  • Item Code: J5020
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 12 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded or rusted fasteners.

Tech Specs

Back To Top
UPC Code 662679160975
Item Length [in] 2.800
Item Weight [lbs] 0.240
Carton Quantity 100
Brand Proto
Country of Origin United States
Drive Size [in] 3/8
Harmonization Code 8204200000
Item Quantity 1
Overall Length [in] 2-3/4
Carton Weight [lbs] 24.570
Mouth Width 2 [in] 43/64
Size [in] 5/8
Bolt Clearance Depth [in] 2-5/16
Box Height [in] 1.750
Box Length [in] 7.500
Carton Height [in] 6.000
Carton Width [in] 5.400
Finish Full Polish
Item Width [in] 0.800
Length Type Deep
Nut Depth [in] 43/64
Point Size 12
Specification_ASME ASME B107.110-2012
Box Quantity 6
Box Weight [lbs] 1.500
Drive End Outside Diameter [in] 7/8
Item Height [in] 0.800
Nut End Outside Diameter [in] 7/8
Box Width [in] 2.500
Carton Length [in] 15.300
Specification_AS AS954E S3.8.1
