3/8 Inch Drive Deep Socket 5/8 Inch - 6 Point - Proto®

  • Item Code: J5020H
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 6 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded or rusted fasteners.

Tech Specs

Back To Top
Bolt Clearance Depth [in] 1-11/16
Carton Weight [lbs] 25.390
Drive End Outside Diameter [in] 7/8
UPC Code 662679161002
Country of Origin United States
Drive Size [in] 3/8
Nut Depth [in] 21/32
Overall Length [in] 2-3/4
Finish Full Polish
Specification_ASME ASME B107.110-2012
Box Weight [lbs] 1.510
Carton Length [in] 15.300
Point Size 6
Harmonization Code 8204200000
Item Width [in] 0.900
Box Height [in] 1.900
Carton Height [in] 6.000
Carton Width [in] 5.400
Item Height [in] 0.900
Item Quantity 1
Item Weight [lbs] 0.250
Length [in] 2-3/4
Length Type Deep
Box Length [in] 7.700
Box Width [in] 2.500
Brand Proto
Carton Quantity 100
Item Length [in] 2.800
Box Quantity 6
Nut End Outside Diameter [in] 7/8
Size [in] 5/8
