3/8 Inch Drive Deep Socket 11/16 Inch - 12 Point - Proto®

  • Item Code: J5022-PROTO
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 12 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded or rusted fasteners.

Tech Specs

Back To Top
Mouth Width 2 [in] 43/64
UPC Code 662679161019
Bolt Clearance Depth [in] 2-5/16
Country of Origin United States
Drive Size [in] 3/8
Item Length [in] 2.800
Item Quantity 1
Box Height [in] 1.750
Carton Height [in] 6.000
Finish Full Polish
Length Type Deep
Point Size 12
Specification_ASME ASME B107.110-2012
Brand Proto
Harmonization Code 8204200000
Nut End Outside Diameter [in] 15/16
Overall Length [in] 2-3/4
Carton Quantity 100
Item Height [in] 1.000
Item Width [in] 1.000
Box Length [in] 7.500
Carton Weight [lbs] 28.200
Carton Width [in] 5.400
Drive End Outside Diameter [in] 15/16
Nut Depth [in] 43/64
Box Width [in] 2.500
Carton Length [in] 15.300
Box Quantity 6
Box Weight [lbs] 1.720
Size [in] 11/16
Item Weight [lbs] 0.300
