3/8 Inch Drive Deep Socket 3/4 Inch - 6 Point - Proto®

  • Item Code: J5024H
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 6 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
UPC Code 662679161040
Carton Quantity 80
Carton Weight [lbs] 26.490
Item Height [in] 1.000
Item Weight [lbs] 0.320
Bolt Clearance Depth [in] 1-23/32
Country of Origin United States
Drive Size [in] 3/8
Item Length [in] 2.800
Item Quantity 1
Length [in] 2-3/4
Box Quantity 6
Item Width [in] 1.000
Size [in] 3/4
Nut Depth [in] 11/16
Point Size 6
Box Width [in] 3.500
Harmonization Code 8204200000
Nose Width [in] 1-1/64
Nut End Outside Diameter [in] 1-1/64
Overall Length [in] 2-3/4
Carton Length [in] 15.300
Drive End Outside Diameter [in] 1-1/64
Box Height [in] 1.370
Box Length [in] 7.500
Brand Proto
Carton Height [in] 6.000
Finish Full Polish
Specification_ASME ASME B107.110-2012
Box Weight [lbs] 1.990
Carton Width [in] 5.400
Length Type Deep
