3/8 Inch Drive Socket 7 mm - 12 Point - Proto®

  • Item Code: J5207M
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 12 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
Nut End Outside Diameter [in] 27/64
UPC Code 662679161187
Length Type Standard
Overall Length [in] 1-3/32
Size [mm] 7
Brand Proto
Finish Full Polish
Item Length [in] 1.100
Point Size 12
Specification_ASME ASME B107.110-2012
Bolt Clearance Depth [in] 45/64
Drive Size [in] 3/8
Item Width [in] 0.500
Box Height [in] 1.250
Box Weight [lbs] 0.320
Item Height [in] 0.500
Box Width [in] 2.250
Box Quantity 6
Country of Origin United States
Length [in] 1-3/32
Nut Depth [in] 1/4
Specification_AS AS954E S3.8.1
Drive End Outside Diameter [in] 43/64
Box Length [in] 4.500
Harmonization Code 8204200000
Item Quantity 1
Item Weight [lbs] 0.050
Nose Width [in] 27/64
