3/8 Inch Drive Socket 8 mm - 12 Point - Proto®

  • Item Code: J5208M
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 12 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
UPC Code 662679161224
Box Quantity 6
Size [mm] 8
Item Height [in] 0.600
Item Quantity 1
Length [in] 1-3/32
Box Height [in] 1.250
Drive End Outside Diameter [in] 43/64
Nut Depth [in] 1/4
Specification_AS AS954E S3.8.1
Box Width [in] 2.250
Box Length [in] 4.500
Harmonization Code 8204200000
Bolt Clearance Depth [in] 45/64
Country of Origin United States
Drive Size [in] 3/8
Finish Full Polish
Item Width [in] 0.600
Point Size 12
Specification_ASME ASME B107.110-2012
Brand Proto
Item Length [in] 1.100
Item Weight [lbs] 0.060
Nut End Outside Diameter [in] 15/32
Box Weight [lbs] 0.360
Length Type Standard
Overall Length [in] 1-3/32
