3/8 Inch Drive Socket 9 mm - 12 Point - Proto®

  • Item Code: J5209M
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 12 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
Bolt Clearance Depth [in] 45/64
Drive Size [in] 3/8
UPC Code 662679161255
Brand Proto
Box Height [in] 1.250
Country of Origin United States
Length [in] 1-3/32
Nut Depth [in] 9/32
Box Quantity 6
Item Weight [lbs] 0.050
Nose Width [in] 33/64
Nut End Outside Diameter [in] 33/64
Specification_AS AS954E S3.8.1
Box Weight [lbs] 0.320
Item Height [in] 0.500
Drive End Outside Diameter [in] 43/64
Item Length [in] 1.100
Item Width [in] 0.500
Finish Full Polish
Point Size 12
Size [mm] 9
Specification_ASME ASME B107.110-2012
Box Length [in] 4.500
Box Width [in] 2.250
Harmonization Code 8204200000
Item Quantity 1
Length Type Standard
Overall Length [in] 1-3/32
