3/8 Inch Drive Socket 11/32 Inch - 12 Point - Proto®

  • Item Code: J5211
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 12 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
UPC Code 662679975708
Box Height [in] 1.300
Brand Proto
Harmonization Code 8204200000
Item Quantity 1
Length [in] 1-3/32
Size [in] 11/32
Country of Origin United States
Item Height [in] 0.700
Item Weight [lbs] 0.060
Nut Depth [in] 23/64
Box Weight [lbs] 0.330
Item Length [in] 1.100
Length Type Standard
Overall Length [in] 1-3/32
Bolt Clearance Depth [in] 21/32
Box Length [in] 4.700
Box Quantity 6
Drive End Outside Diameter [in] 43/64
Specification_AS AS954E S3.8.1
Mouth Width 2 [in] 23/64
Nut End Outside Diameter [in] 1/2
Box Width [in] 2.400
Drive Size [in] 3/8
Finish Full Polish
Item Width [in] 0.700
Point Size 12
Specification_ASME ASME B107.110-2012
