3/8 Inch Drive Socket 11 mm - 12 Point - Proto®

  • Item Code: J5211M
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 12 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
Drive End Outside Diameter [in] 43/64
UPC Code 662679161323
Country of Origin United States
Drive Size [in] 3/8
Harmonization Code 8204200000
Item Quantity 1
Length Type Standard
Mouth Width 2 [in] 21/64
Overall Length [in] 1-3/32
Finish Full Polish
Item Length [in] 1.100
Nut End Outside Diameter [in] 41/64
Size [mm] 11
Specification_ASME ASME B107.110-2012
Length [in] 1-3/32
Bolt Clearance Depth [in] 45/64
Box Length [in] 4.500
Box Width [in] 2.250
Box Height [in] 1.250
Item Weight [lbs] 0.050
Item Width [in] 0.600
Point Size 12
Box Weight [lbs] 0.380
Item Height [in] 0.600
Nut Depth [in] 21/64
Specification_AS AS954E S3.8.1
Box Quantity 6
Brand Proto
Nose Width [in] 41/64
