3/8 Inch Drive Socket 12 mm - 12 Point - Proto®

  • Item Code: J5212M
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 12 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
UPC Code 662679161361
Item Weight [lbs] 0.070
Length Type Standard
Bolt Clearance Depth [in] 1/2
Box Length [in] 4.700
Box Width [in] 2.400
Brand Proto
Harmonization Code 8204200000
Country of Origin United States
Drive Size [in] 3/8
Item Quantity 1
Drive End Outside Diameter [in] 45/64
Item Width [in] 0.600
Length [in] 1-1/8
Nose Width [in] 45/64
Nut End Outside Diameter [in] 45/64
Point Size 12
Item Height [in] 0.600
Specification_AS AS954E S3.8.1
Box Height [in] 1.250
Item Length [in] 1.100
Overall Length [in] 1-1/8
Finish Full Polish
Nut Depth [in] 9/32
Size [mm] 12
Specification_ASME ASME B107.110-2012
Box Quantity 6
Box Weight [lbs] 0.440
