3/8 Inch Drive Socket 13 mm - 12 Point - Proto®

  • Item Code: J5213M
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 12 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
Carton Weight [lbs] 31.200
UPC Code 662679161392
Carton Height [in] 6.000
Finish Full Polish
Item Width [in] 0.700
Point Size 12
Specification_ASME ASME B107.110-2012
Bolt Clearance Depth [in] 1/2
Carton Width [in] 5.400
Box Width [in] 2.250
Carton Quantity 400
Overall Length [in] 1-1/8
Item Quantity 1
Length [in] 1-1/8
Carton Length [in] 15.300
Drive Size [in] 3/8
Size [mm] 13
Box Length [in] 4.500
Harmonization Code 8204200000
Item Length [in] 1.100
Item Weight [lbs] 0.070
Length Type Standard
Box Height [in] 1.250
Box Weight [lbs] 0.480
Brand Proto
Nose Width [in] 47/64
Specification_AS AS954E S3.8.1
Box Quantity 6
Country of Origin United States
Drive End Outside Diameter [in] 47/64
Item Height [in] 0.700
Nut Depth [in] 9/32
Nut End Outside Diameter [in] 47/64
