3/8 Inch Drive Black Oxide Socket 1/2 Inch - 12 Point - Proto®

  • Item Code: J5216B
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 12 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
Length [in] 1-1/8
UPC Code 662679290177
Item Quantity 1
Point Size 12
Specification_ASME ASME B107.110-2012
Box Width [in] 2.250
Brand Proto
Item Weight [lbs] 0.080
Overall Length [in] 1-1/8
Box Length [in] 4.500
Finish Black Oxide
Harmonization Code 8204200000
Item Length [in] 1.100
Length Type Standard
Drive Size [in] 3/8
Item Width [in] 0.500
Box Weight [lbs] 0.470
Bolt Clearance Depth [in] 11/16
Box Quantity 6
Country of Origin United States
Drive End Outside Diameter [in] 47/64
Nut Depth [in] 11/32
Nut End Outside Diameter [in] 47/64
Box Height [in] 1.250
Item Height [in] 0.500
Nose Width [in] 47/64
Size [in] 1/2
Specification_AS AS954E S3.8.1
