3/8 Inch Drive Black Oxide Socket 9/16 Inch - 12 Point - Proto®

  • Item Code: J5218B
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 12 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
UPC Code 662679290184
Box Length [in] 5.500
Finish Black Oxide
Item Length [in] 1.100
Item Quantity 1
Size [in] 9/16
Specification_AS AS954E S3.8.1
Harmonization Code 8204200000
Length [in] 1-1/8
Length Type Standard
Nose Width [in] 51/64
Nut Depth [in] 33/64
Box Height [in] 1.190
Item Height [in] 0.700
Item Weight [lbs] 0.090
Item Width [in] 0.700
Mouth Width 2 [in] 33/64
Point Size 12
Specification_ASME ASME B107.110-2012
Box Weight [lbs] 0.610
Box Width [in] 2.560
Drive End Outside Diameter [in] 51/64
Nut End Outside Diameter [in] 51/64
Overall Length [in] 1-1/8
Bolt Clearance Depth [in] 11/16
Box Quantity 6
Brand Proto
Country of Origin United States
Drive Size [in] 3/8
