3/8 Inch Drive Socket 18 mm - 12 Point - Proto®

  • Item Code: J5218M
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 12 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
UPC Code 662679161576
Box Height [in] 1.250
Drive End Outside Diameter [in] 61/64
Harmonization Code 8204200000
Length Type Standard
Nut Depth [in] 17/32
Box Quantity 6
Item Height [in] 0.900
Overall Length [in] 1-3/16
Length [in] 1-3/16
Nose Width [in] 61/64
Nut End Outside Diameter [in] 61/64
Box Weight [lbs] 0.780
Country of Origin United States
Item Quantity 1
Item Length [in] 1.200
Specification_AS AS954E S3.8.1
Drive Size [in] 3/8
Finish Full Polish
Item Width [in] 0.900
Point Size 12
Specification_ASME ASME B107.110-2012
Bolt Clearance Depth [in] 1/2
Box Length [in] 4.500
Box Width [in] 2.250
Brand Proto
Item Weight [lbs] 0.120
Size [mm] 18
