3/8 Inch Drive Socket 26 mm - 12 Point - Proto®

  • Item Code: J5226M
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 12 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
Bolt Clearance Depth [in] 59/64
UPC Code 662679163242
Box Quantity 6
Country of Origin United States
Length [in] 1-3/8
Specification_AS AS954E S3.8.1
Box Length [in] 7.500
Drive Size [in] 3/8
Item Length [in] 1.400
Item Width [in] 1.300
Mouth Width 2 [in] 49/64
Nut Depth [in] 49/64
Item Weight [lbs] 0.260
Overall Length [in] 1-3/8
Item Height [in] 1.300
Size [mm] 26
Finish Full Polish
Point Size 12
Specification_ASME ASME B107.110-2012
Box Width [in] 2.500
Box Height [in] 1.750
Box Weight [lbs] 1.630
Brand Proto
Drive End Outside Diameter [in] 1-21/64
Nut End Outside Diameter [in] 1-21/64
Harmonization Code 8204200000
Item Quantity 1
Length Type Standard
Nose Width [in] 1-21/64
