3/8 Inch Drive Black Oxide Socket 15/16 Inch - 12 Point - Proto®

  • Item Code: J5230B
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 12 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
Nut End Outside Diameter [in] 1-15/64
UPC Code 662679290276
Box Quantity 6
Box Width [in] 2.500
Brand Proto
Size [in] 15/16
Specification_AS AS954E S3.8.1
Nose Width [in] 1-15/64
Point Size 12
Specification_ASME ASME B107.110-2012
Drive End Outside Diameter [in] 1-9/64
Bolt Clearance Depth [in] 11/16
Item Width [in] 1.200
Length [in] 1-9/16
Nut Depth [in] 23/32
Box Length [in] 7.500
Length Type Standard
Overall Length [in] 1-9/16
Box Weight [lbs] 1.480
Country of Origin United States
Drive Size [in] 3/8
Item Length [in] 1.300
Item Quantity 1
Box Height [in] 1.750
Finish Black Oxide
Item Height [in] 1.200
Item Weight [lbs] 0.230
Harmonization Code 8204200000
