3/8 Inch Drive Universal Joint Socket 8 mm - 6 Point - Proto®

  • Item Code: J5271HAM
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 6 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
Nut End Outside Diameter [in] 29/64
UPC Code 662679996314
Box Height [in] 1.100
Overall Length [in] 1-49/64
Box Quantity 6
Nut Depth [in] 5/16
Size [mm] 8
Bolt Clearance Depth [in] 7/16
Box Weight [lbs] 0.740
Brand Proto
Drive End Outside Diameter [in] 23/32
Point Size 6
Country of Origin United States
Item Height [in] 0.700
Item Length [in] 1.800
Item Quantity 1
Nose Width [in] 29/64
Harmonization Code 8204200000
Length Type Standard
Item Weight [lbs] 0.120
Box Length [in] 4.700
Box Width [in] 2.400
Drive Size [in] 3/8
Finish Full Polish
Item Width [in] 0.700
Outside Head Width 2 [in] 1-49/64
Specification_ASME ASME B107.110-2012
