3/8 Inch Drive Universal Socket 3/8 Inch - 6 Point - Proto®

  • Item Code: J5273HA
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 6 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
Bolt Clearance Depth [in] 27/64
UPC Code 662679994440
Box Height [in] 1.100
Country of Origin United States
Box Weight [lbs] 0.760
Drive End Outside Diameter [in] 23/32
Item Height [in] 0.800
Box Width [in] 2.600
Finish Full Polish
Item Weight [lbs] 0.130
Item Width [in] 0.800
Specification_ASME ASME B107.110-2012
Box Quantity 6
Box Length [in] 5.700
Drive Size [in] 3/8
Size [in] 3/8
Brand Proto
Nut End Outside Diameter [in] 35/64
Overall Length [in] 1-3/4
Point Size 6
Harmonization Code 8204200000
Item Length [in] 1.800
Item Quantity 1
Length Type Standard
Nose Width [in] 35/64
Nut Depth [in] 5/16
