3/8 Inch Drive Universal Joint Socket 10 mm - 6 Point - Proto®

  • Item Code: J5273HAM
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 6 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
UPC Code 662679996321
Harmonization Code 8204200000
Length Type Standard
Overall Length [in] 1-49/64
Point Size 6
Box Width [in] 2.600
Drive End Outside Diameter [in] 23/32
Finish Full Polish
Item Height [in] 0.700
Item Width [in] 0.700
Outside Head Width 2 [in] 1-49/64
Specification_ASME ASME B107.110-2012
Item Weight [lbs] 0.130
Item Length [in] 1.800
Item Quantity 1
Nose Width [in] 35/64
Bolt Clearance Depth [in] 7/16
Box Quantity 6
Nut End Outside Diameter [in] 35/64
Box Length [in] 5.700
Brand Proto
Country of Origin United States
Drive Size [in] 3/8
Nut Depth [in] 11/32
Size [mm] 10
Box Height [in] 1.100
Box Weight [lbs] 0.750
