3/8 Inch Drive Universal Socket 9/16 Inch - 6 Point - Proto®

  • Item Code: J5276HA
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 6 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
UPC Code 662679994471
Drive End Outside Diameter [in] 3/4
Harmonization Code 8204200000
Length Type Standard
Point Size 6
Overall Length [in] 1-7/8
Box Quantity 6
Brand Proto
Box Weight [lbs] 0.830
Item Length [in] 1.800
Item Quantity 1
Item Weight [lbs] 0.130
Size [in] 9/16
Box Width [in] 2.600
Item Height [in] 0.800
Bolt Clearance Depth [in] 3/8
Box Height [in] 1.100
Nut End Outside Diameter [in] 25/32
Box Length [in] 5.700
Country of Origin United States
Drive Size [in] 3/8
Finish Full Polish
Item Width [in] 0.800
Nut Depth [in] 3/8
Specification_ASME ASME B107.110-2012
