3/8 Inch Drive Universal Joint Socket 13 mm - 6 Point - Proto®

  • Item Code: J5276HAM
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 6 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
UPC Code 662679996352
Box Length [in] 5.700
Box Weight [lbs] 0.800
Country of Origin United States
Drive Size [in] 3/8
Finish Full Polish
Outside Head Width 2 [in] 1-49/64
Specification_ASME ASME B107.110-2012
Box Quantity 6
Overall Length [in] 1-49/64
Brand Proto
Box Height [in] 1.100
Box Width [in] 2.600
Item Height [in] 0.700
Item Width [in] 0.700
Drive End Outside Diameter [in] 23/32
Harmonization Code 8204200000
Nut Depth [in] 11/32
Bolt Clearance Depth [in] 7/16
Item Length [in] 1.800
Item Quantity 1
Length Type Standard
Nut End Outside Diameter [in] 23/32
Size [mm] 13
Item Weight [lbs] 0.130
Point Size 6
