3/8 Inch Drive Universal Joint Socket 15 mm - 6 Point - Proto®

  • Item Code: J5278HAM
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 6 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
UPC Code 662679996376
Box Weight [lbs] 0.890
Finish Full Polish
Item Length [in] 2.000
Item Width [in] 0.800
Nut Depth [in] 3/8
Drive End Outside Diameter [in] 23/32
Item Height [in] 0.800
Item Weight [lbs] 0.150
Nut End Outside Diameter [in] 51/64
Size [mm] 15
Box Width [in] 2.600
Specification_ASME ASME B107.110-2012
Box Height [in] 1.100
Country of Origin United States
Drive Size [in] 3/8
Box Quantity 6
Brand Proto
Box Length [in] 5.700
Overall Length [in] 1-7/8
Bolt Clearance Depth [in] 31/64
Harmonization Code 8204200000
Item Quantity 1
Length Type Standard
Nose Width [in] 51/64
Point Size 6
