3/8 Inch Drive Universal Socket 3/4 Inch - 6 Point - Proto®

  • Item Code: J5279HA
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 6 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
UPC Code 662679994501
Brand Proto
Finish Full Polish
Item Length [in] 2.000
Specification_ASME ASME B107.110-2012
Country of Origin United States
Harmonization Code 8204200000
Item Quantity 1
Box Width [in] 2.100
Drive Size [in] 3/8
Box Length [in] 6.900
Box Quantity 6
Item Height [in] 1.000
Item Weight [lbs] 0.170
Nut Depth [in] 13/32
Nut End Outside Diameter [in] 1
Size [in] 3/4
Box Height [in] 1.500
Box Weight [lbs] 1.010
Drive End Outside Diameter [in] 3/4
Overall Length [in] 2
Bolt Clearance Depth [in] 15/32
Item Width [in] 1.000
Point Size 6
Length Type Standard
