3/8 Inch Drive Universal Joint Socket 16 mm - 6 Point - Proto®

  • Item Code: J5279HAM
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 6 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
UPC Code 662679996383
Drive End Outside Diameter [in] 23/32
Overall Length [in] 1-57/64
Bolt Clearance Depth [in] 33/64
Harmonization Code 8204200000
Item Quantity 1
Length Type Standard
Outside Head Width 2 [in] 1-57/64
Country of Origin United States
Item Weight [lbs] 0.150
Nose Width [in] 55/64
Nut End Outside Diameter [in] 55/64
Size [mm] 16
Box Weight [lbs] 0.910
Brand Proto
Point Size 6
Box Height [in] 1.100
Box Quantity 6
Item Height [in] 0.900
Item Length [in] 2.000
Nut Depth [in] 13/32
Box Length [in] 5.700
Box Width [in] 2.600
Drive Size [in] 3/8
Finish Full Polish
Item Width [in] 0.900
Specification_ASME ASME B107.110-2012
