3/8 Inch Drive Universal Socket 13/16 Inch - 12 Point - Proto®

  • Item Code: J5280A
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 12 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
Drive End Outside Diameter [in] 25/32
UPC Code 662679994396
Finish Full Polish
Item Height [in] 1.100
Item Length [in] 2.200
Point Size 12
Specification_ASME ASME B107.110-2012
Brand Proto
Country of Origin United States
Drive Size [in] 3/8
Harmonization Code 8204200000
Item Quantity 1
Item Weight [lbs] 0.190
Length Type Standard
Box Weight [lbs] 1.150
Box Width [in] 2.600
Nut End Outside Diameter [in] 1-3/32
Bolt Clearance Depth [in] 9/16
Nut Depth [in] 13/32
Box Quantity 6
Item Width [in] 1.100
Box Height [in] 1.800
Box Length [in] 7.700
Overall Length [in] 1-7/8
Size [in] 13/16
Specification_AS AS954E S3.8.1
