3/8 Inch Drive Universal Joint Socket 17 mm - 6 Point - Proto®

  • Item Code: J5280HAM
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 6 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
UPC Code 662679996390
Box Height [in] 1.100
Brand Proto
Box Length [in] 5.700
Drive Size [in] 3/8
Nut End Outside Diameter [in] 15/16
Point Size 6
Box Quantity 6
Country of Origin United States
Item Height [in] 1.000
Item Length [in] 2.000
Item Weight [lbs] 0.170
Box Width [in] 2.600
Drive End Outside Diameter [in] 23/32
Overall Length [in] 1-57/64
Finish Full Polish
Specification_ASME ASME B107.110-2012
Bolt Clearance Depth [in] 33/64
Harmonization Code 8204200000
Item Quantity 1
Length Type Standard
Outside Head Width 2 [in] 1-57/64
Box Weight [lbs] 1.000
Item Width [in] 1.000
Nut Depth [in] 13/32
Size [mm] 17
