3/8 Inch Drive Universal Joint Socket 18 mm - 6 Point - Proto®

  • Item Code: J5281HAM
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 6 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
UPC Code 662679996406
Box Height [in] 1.100
Item Height [in] 1.000
Item Weight [lbs] 0.170
Box Quantity 6
Nose Width [in] 63/64
Bolt Clearance Depth [in] 33/64
Drive End Outside Diameter [in] 23/32
Item Width [in] 1.000
Length Type Standard
Point Size 6
Item Quantity 1
Nut Depth [in] 7/16
Box Weight [lbs] 0.990
Brand Proto
Harmonization Code 8204200000
Outside Head Width 2 [in] 1-57/64
Overall Length [in] 1-57/64
Size [mm] 18
Box Length [in] 5.700
Box Width [in] 2.600
Country of Origin United States
Drive Size [in] 3/8
Finish Full Polish
Item Length [in] 2.000
Nut End Outside Diameter [in] 63/64
Specification_ASME ASME B107.110-2012
