3/8 Inch Drive Universal Socket 15/16 Inch - 12 Point - Proto®

  • Item Code: J5282A
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 12 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
Bolt Clearance Depth [in] 5/8
Outside Head Width 2 [in] 1-61/64
Overall Length [in] 1-61/64
UPC Code 662679994419
Box Width [in] 2.600
Nut Depth [in] 17/32
Box Quantity 6
Size [in] 15/16
Drive End Outside Diameter [in] 25/32
Specification_AS AS954E S3.8.1
Drive Size [in] 3/8
Finish Full Polish
Item Width [in] 1.300
Point Size 12
Specification_ASME ASME B107.110-2012
Box Length [in] 7.700
Box Weight [lbs] 1.230
Harmonization Code 8204200000
Length Type Standard
Country of Origin United States
Item Length [in] 2.200
Item Quantity 1
Brand Proto
Item Height [in] 1.300
Nut End Outside Diameter [in] 1-1/4
Box Height [in] 1.800
Item Weight [lbs] 0.210
