1/2 Inch Drive Deep Impact Socket 33 mm - 6 Point - Proto®

  • Item Code: J7333M
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 6 Point Impact Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
Drive End Outside Diameter [in] 1-55/64
Mouth Width 2 [in] 1-25/64
UPC Code 662679977269
Item Height [in] 1.900
Nut End Outside Diameter [in] 1-55/64
Overall Length [in] 3-1/2
Harmonization Code 8204200000
Item Quantity 1
Nose Width [in] 1-55/64
Country of Origin United States
Drive Size [in] 1/2
Length [in] 3-1/2
Box Length [in] 13.600
Box Width [in] 4.200
Item Weight [lbs] 1.480
Point Size 6
Bolt Clearance Depth [in] 2-27/32
Box Height [in] 2.000
Brand Proto
Item Length [in] 3.500
Length Type Deep
Box Quantity 6
Box Weight [lbs] 8.890
Finish Black Oxide
Nut Depth [in] 1-25/64
Size [mm] 33
Item Width [in] 1.900
Specification_ASME ASME B107.110-2012
