1/2 Inch Drive Deep Impact Socket 34 mm - 6 Point - Proto®

  • Item Code: J7334M
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 6 Point Impact Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
UPC Code 662679977276
Drive End Outside Diameter [in] 1-15/16
Item Weight [lbs] 1.500
Overall Length [in] 3-1/2
Country of Origin United States
Length [in] 3-1/2
Point Size 6
Box Weight [lbs] 9.000
Harmonization Code 8204200000
Item Quantity 1
Box Length [in] 13.600
Box Quantity 6
Box Width [in] 4.200
Item Height [in] 1.900
Drive Size [in] 1/2
Item Width [in] 1.900
Size [mm] 34
Specification_ASME ASME B107.110-2012
Bolt Clearance Depth [in] 2-27/32
Brand Proto
Finish Black Oxide
Mouth Width 2 [in] 1-25/64
Nut Depth [in] 1-25/64
Nut End Outside Diameter [in] 1-15/16
Box Height [in] 2.000
Item Length [in] 3.500
Length Type Deep
