1/2 Inch Drive Impact Socket 41 mm - 6 Point - Proto®

  • Item Code: J7441M
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 6 Point Impact Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
Box Weight [lbs] 7.100
Drive End Outside Diameter [in] 2-19/64
Mouth Width 2 [in] 1-21/64
Nose Width [in] 2-19/64
Nut End Outside Diameter [in] 2-19/64
UPC Code 662679977245
Drive Size [in] 1/2
Length [in] 2-19/50
Brand Proto
Finish Black Oxide
Item Width [in] 2.300
Item Weight [lbs] 1.200
Specification_ASME ASME B107.110-2012
Box Width [in] 3.300
Item Length [in] 2.300
Bolt Clearance Depth [in] 1-17/32
Box Height [in] 2.500
Country of Origin United States
Item Height [in] 2.200
Item Quantity 1
Box Length [in] 15.700
Harmonization Code 8204200000
Length Type Standard
Nut Depth [in] 1-21/64
Overall Length [in] 2-3/8
Point Size 6
Box Quantity 6
Size [mm] 41
