1/2 Inch Drive Impact Socket 46 mm - 6 Point - Proto®

  • Item Code: J7446M
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Proto® 6 Point Impact Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
Bolt Clearance Depth [in] 1-17/32
Box Weight [lbs] 8.240
Length [in] 2-43/100
UPC Code 662679977252
Item Weight [lbs] 1.240
Nut End Outside Diameter [in] 2-3/8
Item Length [in] 2.500
Item Width [in] 2.500
Point Size 6
Length Type Standard
Nut Depth [in] 63/64
Box Height [in] 2.500
Box Quantity 6
Country of Origin United States
Mouth Width 2 [in] 63/64
Box Width [in] 3.300
Brand Proto
Drive Size [in] 1/2
Finish Black Oxide
Overall Length [in] 2-7/16
Drive End Outside Diameter [in] 2-3/8
Item Height [in] 2.300
Specification_ASME ASME B107.110-2012
Box Length [in] 15.700
Harmonization Code 8204200000
Item Quantity 1
Size [mm] 46
