1/2 Inch Drive Deep Universal Impact Socket 14 mm - 6 Point - Proto®

  • Item Code: J75414MP
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Ball and spring design which allows for a 30° working angle.
    • Smooth 360° rotation.
    • Proto® 6 Point Impact Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
UPC Code 662679006631
Bolt Clearance Depth [in] 1-5/8
Box Weight [lbs] 2.690
Item Width [in] 1.100
Point Size 6
Box Height [in] 1.300
Box Length [in] 7.700
Harmonization Code 8204200000
Item Height [in] 1.100
Item Quantity 1
Length Type Deep
Drive Size [in] 1/2
Brand Proto
Overall Length [in] 3-1/2
Box Quantity 6
Drive End Outside Diameter [in] 1-1/16
Finish Black Oxide
Item Weight [lbs] 0.450
Nut Depth [in] 11/16
Item Length [in] 3.500
Size [mm] 14
Box Width [in] 3.600
Country of Origin United States
