1/2 Inch Drive Deep Universal Impact Socket 19 mm - 6 Point - Proto®

  • Item Code: J75419MP
  • Brand: Proto
  • Unit Size: 1

Description

Features

Back To Top
    • Ball and spring design which allows for a 30° working angle.
    • Smooth 360° rotation.
    • Proto® 6 Point Impact Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
    • The TorquePlus„¢ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
    • The TorquePlus„¢ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
    • The TorquePlus„¢ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Tech Specs

Back To Top
UPC Code 662679006686
Box Width [in] 3.500
Brand Proto
Harmonization Code 8204200000
Size [mm] 19
Box Length [in] 9.300
Item Weight [lbs] 0.680
Item Width [in] 1.300
Bolt Clearance Depth [in] 1-5/8
Item Length [in] 3.500
Overall Length [in] 3-1/2
Point Size 6
Box Weight [lbs] 4.060
Drive Size [in] 1/2
Finish Black Oxide
Item Quantity 1
Box Height [in] 1.500
Box Quantity 6
Country of Origin United States
Item Height [in] 1.300
Length Type Deep
Drive End Outside Diameter [in] 1-1/4
Nut Depth [in] 11/16
