20N Superchuck Ball Bearing 1 Inch Chuck

  • Item Code: JCM30239
  • Brand: Jacobs
  • Unit Size: 1

Description

Features Tech Specs

Features

Back To Top
    • Ball Bearing Construction Maximizes Gripping Force and Drilling Accuracy.
    • Jaws Center-Ground for Straightness and Alignment.
    • One-Piece Sleeve Eliminates Crack Between Driving Teeth Often Found in Other Designs.
    • Through-Hardened Sleeve Teeth Plus Hardened Nose and Keyholes Provide Outstanding Wear Resistance.
    • Fluted Sleeve Standard.
    • Each Chuck 100% Inspected for Performance and Precision.
    • T.I.R. 0.003" Maximum at Half Capacity.

Tech Specs

Back To Top
Closed Length 5.5 in
Key Number K5
Long Description 20N Superchuck Ball Bearing 1" Chuck
Maximum Capacity 1.000 in
Minimum Capacity 0.375 in
Mount 5JT
Open Length 4.23 in
Sleeve Outer Diameter 3.65 in
UPC 095456302396
Brand Jacobs
Weight (Catalog) 7.62 lb
Packaging Boxed
Type Chucks
Country of Origin Taiwan
Application Machine Tool
Model Number 20N
